28
CODE- MODEL
CM910 – HP8
CM910L - HP8L
MAXIMUM CAPACITY 135kg
SEAT 46 cm
REAR WHEELS 320 mm x 60 mm
FRONT WHEELS 200 mm x 50 mm
ROLL-OVER PROTECTION WHEELS 35 mm x17 mm x 2pcs
MAXIMUM SPEED 6Km
BATTERY SPECIFICATIONS 12V 34Ah x 2pz
BATTERY DURATION 32km
BATTERY CHARGER TYPE 5Amp, external, 120/240 Volt, 50/60 Hz
CONTROLLER VSI 50Amp
MOTOR 3900rpm 200W x 2pcs
WEIGHT WITH BATTERY 66kg
WEIGHT WITHOUT BATTERY 42kg
STEERING RADIUS 865 mm
SUSPENSION NO
LENGTH 1085 mm
DEPTH 640 mm
HEIGHT 950 mm
SEAT WIDTH 460 mm
SEAT HEIGHT 508 mm
SEAT DEPTH 406 mm
BACKREST HEIGHT 406 mm
WHEELBASE 520 mm
LEG REST 400 mm~500 mm
HEIGHT FROM THE GROUND 80 mm
MAXIMUM SLOPE
SAFETY
10°
MAXIMUM SLOPE 12°
SURMOUNTING OF AN OBSTACLE 50 mm
