Clean
Air
Outlet
Compressed
Air Supp ly
Goyen
Valve
Hop per
Dirty
Air Inlet
Blower On
Normal Operation
Blower On
Filter C leaning
Operatio n
Goyen valves open
in sequence f rom top
to bottom knocking
dust out of the filters
Filters
OPERATIONAL DIAGRAM
Throughout normal operation, the dust laden air enters the dust collector through the dirty a ir inlet ple num. The dirty air f lows
downward towards the hopper and the f ilters remove the f ine dust allowing clean filtered a ir to pass through the f ilters and out
past the blower f an.
Filter cleaning occurs when a signa l f rom the dust collector control pane l is sent to open the goyen v alves allowing a rush of air to
go through the filter bank knock ing the dust out of the f ilters and down into the hopper.
Dirty
Air Inlet
Clean
Air
Outlet
