Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31
Document code: MN674-A003_ENG Revision 1.000 Page 8 of 30
POWER SUPPLY:
The devices can be powered between a wide range of tensions. For more details see the two
tables below.
VAC
VDC
Vmin Vmax Vmin Vmax
HD674-A003-Exx-xx
8V 26V 10V 40V
Consumption at 24V DC:
Device W/VA
HD674-A003-Exx-xx 4
Note: It is possible to use also negative tensions. In this case the polarity must be
inverted.
Caution: Not reverse the polarity power
HD674-A003-E4x-xx
HD674-A003-E7x-xx
