INSTALLATION PROCEDURE
1. Remove all packaging.
2. Read instructions and retain for future reference.
3. Fit unit to wall and observe spacing instructions.
4. Remove front plate and store in a safe place.
5. Fit trunking (4" minimum) to desired option.
6. Install all input supply wiring to National Wiring Regulations
and other applicable Regulations.
7. Install all output load wiring to National
Wiring Regulations
and other applicable Regulations.
8. Install all low voltage control wiring.
9. Set all switches and jumper links.
10. Ensure that all wiring is tidy and that all ventilation grilles are
unobstructed.
11. Switch on supply to unit.
12. Test all loads are operating correctly.
13. Set "start" address.
14. Program operating system.
15. Test operation.
16. Re-fit front plate.
