IDENTIFICATION OF TERMINALS TP-06-09 (9 CHANNEL)
PHASE INPUT NEONS
DMX / SCENARIO
INPUT TERMINALS
ANALOGUE INPUT /
OUTPUT TERMINALS
START ADDRESS
AND FUNCTION SWITCHES
MAINS INPUT
TERMINALS
CHANNEL OUTPUT
TERMINALS
EMERGENCY
TERMINALS
AND MCBÌS
