Modern Forms Slim - 04 Package Contents

9FR-W2003
NOTE: ** denotes nish code of fan
*** denotes blade sweep of fan
1
9
6
3
8
14
5
4
13
2
7
10
12
11
Remote
Control
F-RCBT-WT
Canopy Ring
Adapter Plate
Coupling
Cover
Safety Cable
6.5” x 19 x 2mm
Flat washer
(1pcs)
Safety Cable
#10 x 76mm
Pan head
Philips wood screw
(1pc)
Safety Cable
3/16” (5.2 x 8.4
x1mm)
Spring washer (1pc)
Hardware Bag
RPL-FR2003-PARTS
Blade Screws
3/16*12 mm
Philip washer head
screws (10pcs)
Flywheel Screws
1/4” x 11mm
Phillips/Slotted pan
head screws (6pcs)
Canopy
Motor Housing
Fan Blade
RPL-F2003-***-BD-**
Package Contents
04
Downrod
Assembly
RPL-F2003-HGR-**
Mounting
Bracket
RPL-F2003-HGR-**
PC Shade
RPL-F2003-GLA
Luminaire Cover
RPL-F2003-COVER-**
Luminaire Module
F3IN-120V-R1-30
Receiver
F-R3-2003-052
Motor Assembly
RPL-F2003-HGR-**
