Modine Manufacturing DFP - Replacement Parts Ordering; Model Identification

22
5-564
REPLACEMENT PARTS ORDERING
Ordering
When servicing, repairing or replacing parts on these units,
locate the serial plate of the unit and always give the complete
Model Number and Serial Number from the serial plate. The
serial plate is located on the door of the electrical control box or
MODEL IDENTIFICATION
1 - Product Type (PT)
D - Indoor HVAC Unit
2 - Unit Configuration (UC)
F - Furnace
3 - Venting (V)
P - Power
4,5,6 - Furnace Input Rating (MBH)
75 - 75,000 Btu/Hr Input
100 - 100,000 Btu/Hr Input
125 - 125,000 Btu/Hr Input
150 - 150,000 Btu/Hr Input
175 - 175,000 Btu/Hr Input
200 - 200,000 Btu/Hr Input
225 - 225,000 Btu/Hr Input
250 - 250,000 Btu/Hr Input
300 - 300,000 Btu/Hr Input
350 - 350,000 Btu/Hr Input
400 - 400,000 Btu/Hr Input
7 - Heat Exchanger/Burner/Drip Pan Material (HE)
A - Aluminized Steel
S - 409 Stainless Steel Heat Exchanger/Burner
T - 409 Stainless Steel Heat Exchanger/Burner/Drip Pan
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
PT UC V MBH HE DS AS ATR GT GV SS SV TR
Figure 22.1 - Serial Number Designations
101 26 00-1000
SERIES IDENTITY
NUMBER
Identifies which series
of controls were
furnished on the unit.
SEQUENCE
NUMBER
YEAR OF
MANUFACTURE
00 – 2000
01– 2001
etc.
WEEK OF
MANUFACTURE
01 – 1st week of year
26 – 26th week of year
8 - Development Sequence Designation (DS)
F - Single Stage M - 2-stage or Modulating
9 - Access Side (AS)
R - Right Hand L - Left hand
10 - Air Temperature Rise (ATR)
N - Not Used
11 - Gas Type (GT)
N - Natural with ignition controller
P - Propane with ignition controller
12 - Gas Valve (GV)
1 - Single Stage 5 - Electronic Modulation Master
2 - Two Stage 6 - Electronic Modulation Slave
3 - Mechanical Modulation 7 - Electronic Modulation 0-10 Vdc
4 - Electronic Modulation External Input
Input 8 - Electronic Modulation 4-20mmA
External Input
13 - Additional Safety Switches (SS)
4 - No Switches (Standard) 1 - Low Gas Pressure Switch
0 - No Switches (Premium) (Premium)
2 - High Gas Pressure Switch
(Premium)
3 - High and Low Gas Pressure
Switch (Premium)
14 - Supply Voltage (SV)
A - 115/60/1 E - 230/60/3
B - 208/60/1 F - 460/60/3
C - 230/60/1 G - 575/60/3
D - 200-208/60/3
15 - Transformer (TR)
1 - 40 VA 3 - 150 VA 0 - None
2 - 75 VA 4 - 250 VA
Indoor Power Vented Duct Furnace Model Nomenclature
on the side of unit. The Modine Manufacturing Company part
number for some common replacement parts are listed on the
sample serial plate For a complete description of the model
number, see Model Identification.
