Modine Manufacturing PTC - BLOWER PERFORMANCE DATA - MODEL BTC

20
6-563.7
BLOWER PERFORMANCE DATA - MODEL BTC
Table 20.1 - Power Code Description - Blower Model BTC - 
Table 20.2 - Filter Static Pressure Drop 
BTC215 BTC260 BTC310
Filter Static ("W.C.) 0.1 0.1 0.1
 Calculated at 55°F ATR, for blower units with enclosure and lter, add lter static
to external static pressure
.
 For selection of correct power code, refer to the tables on page 21.
Power
Code
Voltage Phase
BTC215 BTC260 BTC310
HP Drive HP Drive HP Drive
02 115/230 1 1 270 1-1/2 261 1-1/2 261
08 208-230/460 3 1 269 2 268 3 260
11 575 3 1 269 2 268 3 260
13 115/230 1 1-1/2 270 1-1/2 263 1-1/2 263
19 208-230/460 3 1-1/2 269 3 260 5 260
22 575 3 1-1/2 269 3 260 5 260
24 115/230 1 1 272 1-1/2 266 1-1/2 266
30 208-230/460 3 2 269 5 260 1-1/2 262
33 575 3 2 269 5 260 1-1/2 262
35 115/230 1 1-1/2 272 - - - -
41 208-230/460 3 3 271 1-1/2 262 2 262
44 575 3 3 271 1-1/2 262 2 262
46 115/230 1 1 274 - - - -
52 208-230/460 3 1 273 2 262 3 278
55 575 3 1 273 2 262 3 278
57 115/230 1 1 277 - - - -
63 208-230/460 3 1-1/2 273 3 278 1-1/2 264
66 575 3 1-1/2 273 3 278 1-1/2 264
74 208-230/460 3 2 273 1-1/2 264 2 264
77 575 3 2 273 1-1/2 264 2 264
80 575 3 1 275 2 264 3 265
83 575 3 1 276 1-1/2 267 1-1/2 267
84 208-230/460 3 1 275 2 264 3 265
85 208-230/460 3 1 276 1-1/2 267 1-1/2 267
