User Manual MODSTER Trainstar Ascent
www.modster.at 15
1. Install hinge control horns to reserved position on
vertical tail and horizontal tail. Make sure the two plastic
parts are well secured to the foam.
3. Install control arm to servo, using a PWA2.3*4 screw.
Repeat this step to the servo at the other side of fuselage.
5. Install the tail whell to the fuselage, using 2pcs PA2.6*8
screws.
4. Install the horizontal tail and vertical tail to the fuselage,
using 4pcs PA2.6*8 screws.
6. Install the front wheels to the landing gear, using 2pcs
PA2.6*8 screws.
2. Install vertical tail and horizontal tail,
using 2pcs PA2.6*8 screws.
Installation Guide
