16 | PageRev C | 1/22/20
Optional adjustable anchor brackets are provided for securing the Select Instant Wall to a wall for
added stability. Anchor brackets can be adjusted, up to 10" long, to accomodate stem walls and
other obstructions that prevent your cabinets from sitting fl ush against the wall.
Step 1 Each bracket comes with a pre-formed offset end which fi ts in the wall channel.
Bend the other end to the desired length up to 4". Trim if necessary.
Two brackets can be bolted together for lengths up to 10" .
Step 2 Hook the offset end of the brackets into the Instant Wall panels at an ends of the wall.
Bolt the brackets to the Instant Wall using the top hole in the panel. Secure the
brackets to the wall using appropriate mounting hardware (not provided by Moduline).
You may be able to conceal the anchors by putting them on the second panel in from the ends.
However, access in this area may be limited so installing them this way may be challenging.
ANCHOR BRACKETS
