Moduline Select Series - Closet Assembly

8 | PageRev C | 1/22/20
CLOSET
 Closet Door Assembly (x1)
 Rear Brace (x1)
 Toe Kick Front (x1)
 Closet Side (x2)
 Shelf (x1)
 Toe Kick Side (x2)
 Closet Top (x1)
 Bottom Pan (x1)
 Toe Kick Rear (x1)
8-32 x 5/16” Flat Head Bolt w/ Nut (x8)
10-24 x 3/8” Self Tapping Screw (x27)
10-32 x 1” Pan Head Bolt w/ Nut (x8)
1/4-20 x 1/2” Hex Bolt w/ Nut (x2)
Shim (1 sheet of 9)





