- 16 -
1. Press the power button for 3 seconds.
2. Enter the 4-letter PIN code. The default
PIN code is “AAAA”.
3. The mower will now await further
instruction in standby mode.
1. Press START button
2. Close the cover to start
3. Note: If the battery is below 70% charge,
the mower
enters ‘charge to work’ mode
until it reaches 90% charge. If lower than
30% the mower returns to base station to
charge.
In standard mowing mode the mower will
proceed in a random fashion around your
garden, changing direction each time it
reaches the boundary wire.
1. Press the power button for 3 seconds.
Start mowing
Power on Power o
2
1 1
