1. Power on/off (Disabling device)
2. Wear protective gloves
3. Turn the mower upside-down
4. Place blade over raised screw-hole.
- 24 -
Re-orientate the blade (turn it around or
turn it upside down) as each corner wears
out until all four quarters of the blade have
been used. If all four quarters have been
used, then replace blade.
5. Use a second screwdriver to anchor the
blade plate while you attach the blade.
6. Using a cross head screwdriver, secure
the blade on the blade plate. The blade
should be able to rotate freely once fitted.
7. Repeat for other blades
Carry the mower by the handle between
the two rear wheels with the blades
pointing outwards.
Sharp edge
Sharp edge
Replacing the blades
