2. The top of the stem of the cartridge (D) matches the
profile inside the flow extension (C). Slide the flow
extension (C) onto the stem of the cartridge (D) and use
a Phillips screwdriver to tighten the cartridge screw (B).
3. Slide the cartridge nut (A) into the valve body (E) and
position the wrench on the flat sides of the cartridge nut
(A). Rotate the cartridge nut (A) clockwise until it is tight,
then rotate it an additional 1/8 turn.
For additional information on Moen products visit solutions.moen.com and select the type of product you are repairing.
The guide will contain repair details, troubleshooting and specific information on assembling handles associated with
that style of product.
