Moen ET900 - Adjustable Dial Functions; Dial Activity and Light Indicators; Dial Function Details

INS12982- 06/23
ADJUSTABLE DIAL FUNCTIONS:
Briefly press the adjustable dial once to
execute a flushing command.
Knob light color : lake blue
A
B
C
A. FRONT WASH
Must be seated on toilet for operation to work.
Rotate the adjustable dial counterclockwise or
backward 45 degrees to start the front wash
mode which starts cleaning. Wash for 1.5
minutes, drying for 4 minutes followed by flush.
Dial adjusts warm airflow speed.
(This function is limited to ET1100 ET1300 ET2200)
Knob light color : pink
B. POWER/STOP
Turn product on/off or stop
an operating function.
C. REAR WASH
Must be seated on toilet for operation to work.
Rotate the adjustable dial clockwise or forward
45 degrees to start the rear wash mode which
starts cleaning. Wash for 1.5 minutes, drying for
4 minutes followed by flush.
Dial adjusts warm airflow speed.
(This function is limited to ET1100 ET1300 ET2200)
Knob light color : blue
QSG00036 - 11/02
LIGHT TEMPERATURE INDICATORSFUNCTION OF PRODUCT ACTIVITY
No functions operating;
no one sitting on the toilet seat.
White
No functions operating;
user sitting on the toilet seat.
Green
Rear washing activating. Blue
Front washing activating. Pink
Flushing mode activated. Aqua Blue
Drying mode activated. Yellow
UV Activation for Enhance Cleanliness Purple
