28 Appendix A. Specifications
Parameter
Specification
Output
SLOW OUT
SMA, 50 Ω, BW 20 kHz
FAST OUT
SMA, 50 Ω, BW > 20 MHz
MONITOR 1, 2
SMA, 50 Ω, BW > 20 MHz
TRIG
SMA, 0 to +5 V
POWER A, B
M8 female connector, ±12 V, 125 mA
All outputs are limited to ±5 V.
50 Ω outputs 20 mA max (20 mW, +13 dBm).
Mechanical & power
IEC input
110 to 130V at 60Hz or
220 to 260V at 50Hz
Fuse
5x20mm anti-surge ceramic 250 V/2.5 A
Dimensions
W×H×D = 250 × 79 × 292 mm
Weight
2 kg
Power usage
< 10 W
