What to do if the output fuse for a zone fails in my Mold-Masters TempMaster MT Temperature Controller?
If the output fuse fails, it indicates a fault external to the controller. Replace the fuse with one of the same rating and type, specifically a High Rupture Current load fuse. The fuse is located on the control card.
Why is my Mold-Masters TempMaster MT showing a LINE error message?
The absence of mains supply synchronisation pulses can cause a LINE error message. This is commonly due to a missing phase or incorrectly wired plug (swapped phase and neutral). Switch off and isolate the controller, then check the supply wiring to ensure all three phases are present.
What to do if my Mold-Masters TempMaster MT shows a REV alarm?
A REV alarm indicates a shorted or reversed thermocouple. If the REV alarm persists, switch off the controller and investigate the zone in question. You can also slave the affected zone to a working zone temporarily.
Why is there little or no temperature rise in a zone of my Mold-Masters Temperature Controller?
If little or no temperature rise is detected in a zone, check the thermocouple wiring for reversals. Also, inspect the heater wiring for faults or an open circuit in the element.
What to do when Mold-Masters TempMaster MT Temperature Controller detects an open circuit thermocouple?
If an open circuit thermocouple is detected, you can either slave that control zone to an adjacent zone or change to open loop control for immediate recovery.
Why does my Mold-Masters TempMaster MT show earth faults after being idle?
Earth faults can occur if a tool has been idle and moisture has entered a heater. If you can identify the faulty heater, use adjacent heaters to heat it up and dry it out.
General| Category | Temperature Controller |
|---|---|
| Series | MT Series |
| TC/TT Zones | 1 to 24 zones |
| Amperage | Depends on model |
| Thermocouple Types | J, K, T, E |
| Control Modes | PID |
| Connectivity | Ethernet |
| Display Resolution | 0.1°C |
| Input Type | Thermocouple |
| Output Type | SSR |
| Communication Interface | Ethernet |
| Power Supply | 100-240V AC, 50/60Hz |
| Protection Features | Overtemperature |
Defines the intended application for MT Series controllers in plastic molding.
Provides information on the manual's version and release date.
Directs users to order documentation for warranty specifics.
Outlines the procedure for returning parts to Mold-Masters.
Guidelines for product relocation and resale outside the country of destination.
States copyright information and acknowledges related entities.
Lists units and their conversion factors used in the manual.
Lists registered trademarks and U.S. Patents for Mold-Masters products.
Lists the locations of Mold-Masters global manufacturing facilities.
Provides contact details for regional support offices worldwide.
Lists international representatives for various countries.
Emphasizes user/employer responsibility for safety standards and training.
Identifies common hazards associated with injection molding equipment.
Details operational risks and necessary precautions during equipment use.
Explains the meaning of various safety symbols used in the manual.
Outlines essential checks for power supply and controller-to-mold wiring.
Details lockout/tagout procedures and associated hazards.
Provides a step-by-step guide for safe electrical lockout procedures.
Lists energy forms and their specific lockout guidelines.
Procedures for the safe and environmentally friendly disposal of components.
Specific hazards for MT/MT2 controllers and recommended installation environments.
Lists the general technical specifications for the MT controller.
Explains compatibility and physical differences between TMXL2 and MT controllers.
Refers to wiring details for connecting controllers to tools.
Details cabinet power supply acceptance and requirements.
Recommends an inline filter for power line noise concerns.
Instructions on how to power the controller on and off.
Description of the controller cabinet, power supply, and connections.
Details the main components of controller modules: input circuits, CPU, and output triacs.
Explains the closed-loop operation principles of the MT controller.
How to use the Ramp feature to skip the dwell period for faster heating.
Overview of the program menu structure for MT and MT2 controllers.
Overview of factory default settings and setup modification procedures.
Procedure to logically number higher zones in multi-module systems.
How to change the temperature display between Celsius and Fahrenheit.
How to adjust PID settings for zone response time and characteristics.
How to enable or disable the Ramp feature for faster heating.
Procedure to configure the boost temperature for individual zones.
Procedure to configure standby temperature settings for individual zones.
How to set deviation-based over and under temperature limits for zones.
How to enable or disable the ground fault detection feature.
How to use the leak detection function to trigger alarms.
How the controller responds to a detected thermocouple failure.
How to prevent users from selecting Manual, Standby, or Boost functions.
How to configure external alarm outputs for specific operational states.
Procedure to select the display language for the controller.
How to set the specific operating temperatures for each zone.
How to start and operate the controller in the standard Run Mode.
How to turn off individual zones of the controller.
How to turn off an individual controller module.
How to operate the controller in Manual mode for open-loop working.
How to adjust power and temperature settings in Manual Mode.
How to use Slave Mode for zones with faulty thermocouples.
Options for switching between Standby and Boost modes for zones.
How to put individual zones into Standby mode to prevent material degradation.
Procedure to exit Standby mode and return the controller to Auto mode.
How to activate Boost mode for individual zones for a fixed period.
How to adjust temperature settings using up/down buttons in Auto and Manual zones.
Guidelines for servicing, repair, replacement parts, cleaning, and inspection.
How to restore default settings, perform calibration, and manage user options.
Information on various fuses, overcurrent protection, and troubleshooting fan issues.
How the controller diagnoses faults at the card level using error messages.
Discusses common fault conditions like temperature fluctuations, ground faults, and module removal.
Procedures for safely removing controller modules.
Cable markings and connections for single-phase supply, specific to MT-02-02.
Information on three-phase power designations and configurations.
Details on five-wire star 380VAC power connections and cable markings.
How to configure the terminal block for STAR configuration.
Details for four-wire Delta 240V power connections and cable markings.
How to configure the terminal block for DELTA configuration.
Recommendation for inline filters to mitigate power line noise.
Details on the HAN4A connector for alarm output and input signals.
Shows connections for MT controllers to various tools based on model and region.
General warning and specific configurations for MT-02-02 tool wiring.
Pin configuration and cut-out dimensions for MT-02-02 in UK/Europe.
Pin configuration and cut-out dimensions for MT-02-02 in India.
Pin configuration and cut-out dimensions for MT-02-02 in North America.
Tool connection configuration and cut-out dimensions for MT-04-04 systems.
Tool connection configuration and cut-out dimensions for MT-06-06 systems.
Warning for MT-12-12/MT-18-xx system configurations based on location.
Wiring diagrams and cut-out dimensions for MT-12-12/MT-18-xx in UK/Europe.
Pin configurations for MT-12-12/MT-18-xx in North America.
