AMPLIFIERS
PA Technology 2014
100 V Power Amplifiers
Order No. 17.2910
Mono PA power amplifier
• 1 x 480 W
RMS
• 2-way tone control
• Switchable low cut filter
• Speaker outputs via screw terminals
Model PA-980S
Output power 480 W
RMS
,680W
MAX
Input sensitivity 0.765 mV/10kΩ,bal.
Speaker output 4 Ω, 70/100 V
Frequency range 50-15,000 Hz, ±3dB
Equalizer bass ±10 dB/100 Hz
Equalizer treble ±10 dB/10 kHz
S/N ratio >80dB
THD <2%
Admiss. ambient temp. 0-40 °C
Power supply 230 V~/50 Hz/1,350 VA,
24 V‡/14A
Dimensions 482x135x410 mm, 3 RS
Weight 25.5 kg
Connections
Signal input XLR / screw terminals
Speaker output screw terminals
• Temperature-controlled fan, continuously
adjustable
• Feed-through output (link)
•Mainsoperation or 24 V emergency
power operation
Order No. 17.2100
Mono PA power amplifier
• 1 x 240 W
RMS
• 2-way tone control
• Switchable low cut filter
• Speaker outputs via screw terminals
• Temperature-controlled fan, continuously
Model PA-940S
Output power 240 W
RMS
,340W
MAX
Input sensitivity 0.765 mV/10kΩ,bal.
Speaker output 4 Ω, 70/100 V
Frequency range 50-15,000 Hz, ±3dB
Equalizer bass ±10 dB/100 Hz
Equalizer treble ±10 dB/10 kHz
S/N ratio >80dB
THD <2%
Admiss. ambient temp. 0-40 °C
Power supply 230 V~/50 Hz/520 VA,
24 V‡/18A
Dimensions 482x135x380 mm, 3 RS
Weight 19 kg
Connections
Signal input XLR / screw terminals
Speaker output screw terminals
adjustable
• Feed-through output (link)
•Mains operation or 24 V emergency
power operation
• 482 mm (19") rack installation with
supplied mounting brackets
