PA Technology 2014
100 V Power Amplifiers
Order No. 17.2080
Mono PA power amplifier
• 1 x 120 W
RMS
• Silent operation due to fanless cooling
concept
• 2-way tone control
• Switchable low cut filter
• Speaker outputs via screw terminals
• Feed-through output (link)
•Mains operation or 24 V emergency
power operation
• 482 mm (19") rack installation with
supplied mounting brackets
Order No. 17.4260
PA amplifier module, with 100 V output.
• 1 x 40 W
RMS
• Silent operation due to fanless cooling concept
•Balanced line input (XLR) and unbalanced line input (RCA)
• Speaker output via spring-loaded speaker terminals
• Volume control
• Metal housing with mounting brackets
Model PA-900S AKB-160
Output power 120 W
RMS
,160 W
MAX
40 W
RMS
, 60 W
MAX
Mic input --
Aux input 765 mV (line) 390 mV/26 kΩ, bal.
420 mV/11 kΩ, unbal.
Speaker output 4 Ω, 70/100 V 100 V
Frequency range 50-15,000 Hz, ±3 dB 17-20,000 Hz, -3 dB
Equalizer bass ±10 dB/100 Hz -
Equalizer treble ±10 dB/10 kHz -
S/N ratio >80dB > 80 dB
THD <2% <1%
Power supply 230 V~/50 Hz/300 VA, 230 V~/50 Hz/75 VA
24 V‡/9 A
Admiss. ambient temp. 0-40 °C 0-40 °C
Dimensions 482x88x275 mm, 2 RS 213x55x238 mm
Weight 9.5 kg 3.2 kg
Special feature low cut filter -
Inputs
Aux, phono (signal input) 1 x XLR (line)
1 x XLR, 1 x screw terminal 1xRCA L/R (line)
