Monarch 9825 - Page 149

ENQ Reference Table - Byte #2 (continued)
Char Const.
OFF
Const.
ON
Comp.
Failure
Corr.
Error
Online
Data
Error
Busy Active Online
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
a
01100001
b
01100010
c
01100011
d
01100100
e
01100101
f
01100110
g
01100111
h
01101000
i
01101001
j
01101010
k
01101011
l
01101100
m
01101101
n
01101110
o
01101111
p
01110000
q
01110001
r
01110010
s
01110011
t
01110100
u
01110101
v
01110110
w
01110111
x
01111000
y
01111001
z
01111010
{
01111011
|
01111100
}
01111101
~
01111110
Dec 127
01111111
A "1" indicates the bit is turned on. A "0"
indicates the bit is off.
Status Polling
7-5
