Monitor Audio All Weather In Ceiling Series

All Weather In Ceiling Series
2
ENGLISH
1
Draw around template and mark centre lines if necessary.
Tri-Grip x 3
= 5Kgf/cm; 4.34 lbf/inch; 0.5 NM
88.5 mm (3
1/2
”)
211mm (8
1/4
”)
AWC265 & AWC265-T2
Template
Cut around marked line.
2
3
Connect speaker cables by pushing down on the
terminals and clamping the bare wire in the through
hole. Once connected close the protective cover.
5
Tighten the 3 Tri-Grip screws and replace the protective
screw covers.
See over tightening warning.
6
Fitting the All Weather In Ceiling Series Loudspeakers
4
Guide speaker into cut out.
Fit grilles. They are held in place magnetically and
should ‘snap’ into place.
