Monitor Audio All Weather In Ceiling Series User Manual

monitoraudio.com 3
In-Ceiling Specications
Monitor Audio reserves the right to alter specications without notice.
Owner Information
Product Details
Model: …………………………………..
Product Serial No: …………………………………...
Date of Purchase: ……………………………….……
Dealer Details
Dealer Name …………………………………………………………………….....………………………...................................................
Address ………………………………………………..……………………......…..………………………...................................................
...................................................……………………….………......……...………………………………............................................
E-mail address …………………………………………………......……………………………………....................................................
Telephone Number .………………………………………………………………………………………....................................................
AWC265 AWC265-T2 AWC280 AWC280-T2
Frequency Response 60Hz - 30kHz 60Hz - 30kHz 50Hz - 30kHz 50Hz - 30kHz
Impedance
8 Ohms
4.4 Ohms @190Hz
8 + 8 Ohms
4.5 Ohms @185Hz
8 Ohms
4.5 Ohms @185Hz
8 + 8 Ohms
4.5 Ohms @185Hz
Sensitivity (1W@1m) 88dB 88dB (both channels driven) 89dB 89dB (both channels driven)
Maximum SPL 105.8dBA 105.8dBA 109dBA 109dBA
Power Handling (RMS) 60W 60W 100W 100W
Recommended Amp
Requirements
20 - 60W 20 - 60W 20 - 100W 20 - 100W
Drive Unit Complement
1 x 6.5” C-CAM® bass driver.
1 x 1” (25mm) C-CAM® gold
dome tweeter
1 x 6.5” C-CAM® bass driver.
2 x 1” (25mm) C-CAM® gold
dome tweeter
1 x 8” C-CAM® bass driver.
1 x 1” (25mm) C-CAM® gold
dome tweeter
1 x 8” C-CAM® bass driver.
2 x 1” (25mm) C-CAM® gold
dome tweeter
Adjustment Controls +3db / 0dB / -3dB High Frequency Level Switch Adjustable at the point of installation
Termination
1 x (1 Pair) Gold plated push
style terminals
2 x (2 Pairs) Gold plated push
style terminals
1 x (1 Pair) Gold plated push
style terminals
2 x (2 Pairs) Gold plated push
style terminals
Overall Diameter
(Including Grille)
251.5mm (9
7/8
”) 285 mm (11
1/4
”)
Overall Depth 93.5mm (3
11/16
”) 102.5 mm (4
1/16
”)
Cut Out Diameter 210mm (8
1/4
”) 247 mm (9
3/4
”)
Mounting Depth 88mm (3
7/16
”) 97.55 mm (3
13/16
”)
Fixing Type 3 Position Tri Grip® Dog Leg Fixings
Construction Material Mineral Filled PC-ABS Polymer (RoHS2 Compliant)
Pre construction Bracket CB6 (Purple) CB8 (Green)
Weight 2.14kg (4lb 12oz) 2.8kg (6lb 2oz)
Operating Temp Range -34 - 79°C; -29 - 174°F
Certified for extreme climate conditions: ASTM-B117-11 (Anticorrosion-Salt Mist), ASTM-G154-12a (UV Test),
IP55 (IEC/ CEE Water Splash (front), IP4X (IEC,CEE Water Splash (rear).
