Monitor Audio Monitor Reference Series - Specifications

Monitor Reference Series10
Model MR1 MR2 MR4 MR6 MR Centre
Frequency Response
55Hz - 30kHz 42Hz - 30kHz 36Hz - 30kHz 33Hz - 30kHz 60Hz - 30kHz
Sensitivity
(1w @ 1m)
88dB 90dB 91dB 90dB 91dB
Nominal
Impedance
6 Ohms 6 Ohms 6 Ohms 6 Ohms 6 Ohms
Power Handling (RMS)
70W 100W 150W 150W 120W
Recommended Amp
Requirements
15 - 70W 30 - 100W 30 - 120W 40 - 150W 20 - 120W
Bass Alignment
Bass Reflex –
Rear Ported.
Bass Reflex –
Front Ported.
Bass Reflex -
Front and
Rear Ported.
Bass Reflex -
Front and
Rear Ported.
Sealed Cabinet
Drive unit
Complement
1 x 5.5” MMP
®
II
Bass/ Mid driver.
1 x 1” (25mm)
C-CAM
®
gold dome
tweeter
1 x 6.5” MMP
®
II
Bass/ Mid driver.
1 x 1” (25mm)
C-CAM
®
gold dome
tweeter
1 x 6.5” MMP
®
II
Bass driver.
1 x 6.5” MMP
®
II
Bass/ Mid driver.
1 x 1” (25mm) C-CAM
®
gold dome tweeter
2 x 6.5” MMP
®
II
Bass driver.
1 x 6.5” MMP
®
II
Bass/ Mid driver.
1 x 1” (25mm) C-CAM
®
gold dome tweeter
2 x 5.5” MMP
®
II
Bass/ Mid driver.
1 x 1” (25mm)
C-CAM
®
gold dome
tweeter
External Dimension
H x W x D (mm)
260 x 165 x 180 350 x 185 x 250 850 x 185 x 255 970 x 200 x 300 165 x 460 x 165
External Dimensions
H x W x D (inch)
10
1/4
x 6
1/2
x
7
1/16
13
3/4
x 7
5/16
x
9
13/16
33
7/16
x 7
5/16
x 10
1/16
38
3/16
x 7
7/8
x
11
13/16
6
1/2
x 18
1/8
x 6
1/2
Weight (each)
Kg (lb)
3.5 (7.7) 5.6 (12.3) 12 (26.4) 17.2 (37.8) 6.2 (13.6)
SPECIFICATIONS
MRW-10
Low
Frequency
Limit
Upper
Frequency
Limit
(Variable)
Amplifier
Output
Low Pass
Filter
Alignment
Cabinet
Alignment
Driver
Complement
Input
Impedance
Mains Input
Voltage
(Factory Preset)
External
Dimmensions
(H x W x D)
mm (Inches)
Weight
Kg (lbs)
28Hz 45 - 150Hz 100W
12dB/ octave
filter
Bass Reflex,
18mm
construction
1 x 10”Long
Through Driver
20K Ohms
110 - 120Vac 220 - 240Vac
320 x 280 x 280
12 5/8 x 11 x 11
12.9
(28.4)
