Model RX1 RX2 RX6 RX8 RX-Centre RX-FX
System Format
2 Way 2 Way 2 1/2 Way 3 Way 2 1/2 Way 2 Way
Frequency Response
45Hz - 35kHz 40Hz - 35kHz 38Hz - 35kHz 32Hz - 35kHz 45Hz - 35kHz 60Hz - 35kHz
Sensitivity
(1w @ 1m)
89dB 90dB 90dB 90dB 90dB 89dB
Nominal
Impedance
6 Ohms 6 Ohms 6 Ohms 4 Ohms 6 Ohms 6 Ohms
Maximum SPL (dBA)
111.8 113.8 114.8 116.2 114.8 111.8
Power Handling (RMS)
80W 100W 125W 175W 125W 80W
Recommended Amp
Requirements
25 - 80W 25 - 100W 40 - 125W 50 - 175W 40 - 125W 10 - 80W
Bass Alignment
Bass reflex – rear
ported. HiVe® port
System
Bass reflex – rear
ported. HiVe® port
System
Dual Chamber, Bass
reflex with differential
tuning. Twin HiVe®
port System
Bass reflex. Twin
HiVe® port System
Sealed Cabinet Sealed Cabinet
Crossover Frequency
3.0kHz 2.0kHz
LF: 700Hz
MF/HF: 2.7kHz
LF/MF: 300Hz
MF/HF: 2.2kHz
LF: 500Hz
MF/HF: 3.0kHz
2.1kHz
Drive unit
Complement
1 x 6” RST
®
Bass/ Mid driver.
1 x 1” (25mm)
C-CAM
®
gold dome
tweeter
1 x 8” RST
®
Bass/ Mid driver.
1 x 1” (25mm)
C-CAM
®
gold dome
tweeter
1 x 6” RST
®
Bass driver.
1 x 6” RST
®
Bass/ Mid driver.
1 x 1” (25mm) C-CAM
gold dome tweeter
2 x 6” RST
®
Bass drivers.
1 x 6” RST
®
Bass/ Mid driver.
1 x 1” (25mm) C-CAM
gold dome tweeter
1 x 6” RST
®
Bass driver.
1 x 6” RST
®
Bass/ Mid driver.
1 x 1” (25mm) C-CAM
gold dome tweeter
1 x 6” RST
®
Bass/ Mid driver.
2 x 1” (25mm)
C-CAM
®
gold dome
tweeters
External Dimension
H x W x D
(mm & inch)
312 x 185 x 240mm
12 5/16 x 7 5/16
x 9 7/16”
375 x 230 x 300mm
14 3/4 x 9 1/16
x 11 13/16”
850 x 185 x 250mm
33 7/16 x 7 5/16
x 9 13/16”
900 x 185 x 330mm
35 7/16 x 7 5/16 x 13”
185 x 500 x 200mm
7 5/16 x 19 11/16 x
7 7/8”
300 x 120 x 250mm
11 13/16 x 4 3/4
x 9 13/16”
Plinth Dimensions
H x W x D
(mm & inch)
N/A N/A
25 x 265 x 310mm
1 x 10 7/16
x 12 3/16”
25 x 265 x 388mm
1 x 10 7/16
x 15 1/4”
N/A N/A
Weight (each)
Kg (lb)
6.8 (15) 9.5 (20.88) 16.4 (36.13) 21.76 (47.88) 9.62 (21.13) 4.69 (10.38)
SPECIFICATIONS
