Page #65 background imageLoading...
Page #65 background image
规格
Studio
系统配置 双向 – 3 个喇叭单体
频率响应 48 赫兹 – 60 千赫兹
灵敏度(1 瓦@1 米) 86 分贝
阻抗
"4 欧姆
(最小 2.9 欧姆 @ 3.5
赫兹)"
最大声压(一对,房间
里)
110dBA
功率(RMS) 230 瓦
"推荐的功放功率为 4
欧姆
(RMS)"
40 – 120 瓦
系统排列
双槽低音反射 - HiVe II 端
口系统
中 - 高频分音器频率 2.7 千赫兹
喇叭单体
2 x 4 英寸 RDT II 低、中
音喇叭
1 x MPD 高频传感器
外部尺寸(高 x 宽 x
深)
340 x 156.2 x 361 毫米
13
3/8
x 6
1/8
x 14
13/16
英寸
产品重量 7.58 公斤(16 磅 9 盎司)
颜色 缎面漆黑色,白色和灰色
猛牌公司保留更改规格的权利,恕不另行通知。
中文
monitoraudio.com 63

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Monitor Audio STUDIO and is the answer not in the manual?

Monitor Audio STUDIO Specifications

General IconGeneral
Bass reflexYes
Product colorGray
RMS rated power120 W
Recommended usage-
Audio output channels- channels
Speaker placementTabletop/bookshelf
Satellite speaker type2-way
Satellite speaker weight7580 g
Number of satellite speakers2
Satellite speakers RMS power- W
Satellite speaker sensitivity86 dB
Satellite speaker frequency range48 - 60000 Hz
Satellite speaker tweeters quantity1
Satellite speaker dimensions (WxDxH)156.2 x 360.9 x 340 mm
Satellite speaker crossover frequency2700 Hz
Satellite speaker mid-range driver diameter4 \
Connectivity technologyWired
Finish typeGloss
