Monitor Audio STUDIO User Manual

monitoraudio.com 7
Specifications
Studio
System
Configuration
2 Way – 3 driver
Frequency
Response.
48Hz - 60KHz
Sensitivity (1W@1M).
86dB
Nominal Impedance
4 Ohm
(2.9 Ohm Min @ 3.5kHz)
Maximum SPL
(per pair, in room)
110dBA
Power Handling
(RMS)
120W
Recommended
amplifier power into
4 Ohms (RMS)
40-120W
System Alignments
Dual slot bass reflex -
HiVe II port system
Mid - H.F Crossover
Frequency
2.7kHz
Drive Unit
Complement
2 x 4” RDT II bass/mid-
range driver
1 x MPD high frequency
transducer
External Dimensions
(Including Terminals)
(H x W x D)
340 x 156.2 x 361mm
13
3/8
x 6
1/8
x 141
3/16
inch
Product Weight
7.58Kg (16lb 9oz)
Finishes Available
Satin lacquer finish in black,
white and grey
Monitor Audio reserves the right to alter specifications without notice.
ENGLISH

Monitor Audio STUDIO Specifications

General

Bass reflex	Yes
Product color	Gray
RMS rated power	120 W
Recommended usage	-
Audio output channels	- channels
Speaker placement	Tabletop/bookshelf
Satellite speaker type	2-way
Satellite speaker weight	7580 g
Number of satellite speakers	2
Satellite speakers RMS power	- W
Satellite speaker sensitivity	86 dB
Satellite speaker frequency range	48 - 60000 Hz
Satellite speaker tweeters quantity	1
Satellite speaker dimensions (WxDxH)	156.2 x 360.9 x 340 mm
Satellite speaker crossover frequency	2700 Hz
Satellite speaker mid-range driver diameter	4 \
Connectivity technology	Wired
Finish type	Gloss
