Installation and Operation Manual Eco Connect Convection Ovens | 4/5/7/10-Tray | Steam
FG1BX-UK-MAN-0200 | Rev. A23 (March 2023) MONO 101
Item Part number Description Quantity
1 150-07-01300
Inlet water control unit 1
2 150-19-01700 Top sheet 1
3 150-19-02300 Cover plate 1
4 150-19-02600 Base tray 1
5 150-19-02700 Water tank 1
6 150-25-07100 Junction box 1
7 A900-01-196 Jubilee clip 1
8 A900-01-271 Jubilee clip (40 to 60 mm) 2
9 A900-23-004 Drain tube (2 metres) 1
10 A900-23-027 Flexible tube (duct hose) 1
11 A900-27-187 Plug insert 1
12 A900-34-191 Reducer ¼-in. BSP (male) x
3
/
8
-in. BSPT (male) 1
13 A900-34-244 Reducer ¼-in. BSP (male) x ¼-in. BSPT (male) 1
14 A900-34-245 Elbow 1
15 B811-33-001 Spacer 4
16 B839-17-003 Cable gland type 251 1
17 B842-17-005 Cable gland type 206-6096 1
18 B842-30-003 Thermostat 1
19 B842-40-002 Fan guard 1
20 B842-50-005 Porcelain connecting block 1
21 B869-75-033 Fan 1
22 B867-83-011 Solenoid valve 1
