PART 4 4/5 Tray 40cm x 60cm Oven Spares Section
Oven Code FG153
Figure 32: Rear view with outer sheeting removed (FG153)
A. Motor and Element ....................... (Part 4 / Section 1 on Page 84)
B. Main Panel ................................... (Part 4 / Section 2 on Page 85)
C. Damper and fan............................ (Part 4 / Section 3 on Page 86)
D. Water System ............................... (Part 4 / Section 4 on Page 87)
E. Baking Chamber and Door Parts . (Part 4 / Section 5 on Page 89)
