HARDTAIL BRIDGE (Retro Vision models only)
Replace the strings by feeding the new strings through the holes in the
back of the guitar body, then feed them over the saddles.
Adjust string height using the included Saddle Height Adjustment Wrench
to adjust the Allen screws on each side of the saddles.
Adjust the intonation by moving the saddle forward or backward using the
intonation adjustment screw at the rear of the bridge and a #1 Phillips
screwdriver.
WILKINSON BRIDGE (California Classic models only)
If you want to use the tremolo, insert the tremolo arm into the bridge, then
tighten the tremolo locking screw using the Saddle Height Adjustment and
Tremolo Lock Wrench. If you tighten it all the way, it will lock the tremolo
arm in place, but if you back off a bit from fully tight, the tremolo arm will
be free to swing into and out of playing position.
Change the strings by feeding the strings through the holes in the back of
the guitar body, then feed them over the saddles.
Adjust the overall string height by adjusting the two Allen screws at the
front of the bridge using the Bridge Height Adjustment Wrench.
To adjust the intonation, first use the
Hold Down and Intonation
Adjustment Wrench to loosen the
hold down screw at the top of the
saddle. Next, to move the saddle forward or backward using the intonation
