active, processor controlled, bi-amped speaker system
W400A
Rear panel: equalizer controls
Example 3 :
• MID CTRL in FLAT setting
• "flat/ " filter switched ON
(= pushbutton DOWN)
• "spk/ " filter switched ON
(= pushbutton DOWN)
With this settings, the lowest frequencies are dimmed
in comparison with the previous one.
It is the suggested setting when used as a stage
monitor at low levels, to compensate the low frequency
boost introduced by the stage floor being near to the
speaker.
Example 4 :
• MID CTRL in FLAT setting
• "flat/ " filter switched ON
(= pushbutton DOWN)
• "spk/ " filter switched OFF
(= pushbutton UP)
This is the suggested setting for high level stage
monitoring applications. By reducing the audible range
limits boosting the available dynamic range is
increased.
14
ENGLISH
flat
MID CTLR
flat
spk
flat
MID CTLR
flat
spk
