Eclipse 38
STAY
FORESTAY
INNER
FORESTAY
CAP SHROUD
INTERMEDIATE
FORWARD
LOWER
AFT LOWER
BACKSTAY
QTYPERSET
0
0
2
2
2
2
1
TOP END
FITTING
-
-
Shroud
Shroud
Shroud
Shroud
Eye swaged
BOTTOM END
FITTING
-
-
Rigging screw and
roller
Rigging screw and
roller
Rigging screw and
roller
Rigging screw and
roller
Rigging screw
OVERALL
LENGTH (M)
0
0
13.97
9.665
5.37
5.24
12.0
Eclipse 43
STAY
FORESTAY
INNER
FORESTAY
CAP SHROUD
INTERMEDIATE
FORWARD
LOWER
AFT LOWER
BACKSTAY
BACKSTAY SPAN
QTYPERSET
0
0
2
2
2
2
1
2
TOP END
FITTING
Eye swaged, eye
talurit and tee
Eye swaged, eye
talurit and tee
shroud terminal
Shroud terminal
Shroud terminal
Eye swaged, eye
talurit and shroud
terminal
Eye swaged
Eye swaged
BOTTOM END
FITTING
Rigging screw, eye
and swageless
Rigging screw, eye,
swageless and roller
Rigging screw and
roller
Rigging screw and
roller
Rigging screw and
roller
Rigging screw and
roller
Fork
Rigging screw
OVERALL
LENGTH
16.63
0
15.53
10.93
6.24
6.07
13.60
4.22
Issue 3
Page 2.5
