Moog RKP-II - Mechanical Stroke Adjustment, B1; Fig. 10: Mechanical Stroke Adjustment, B1

3 Product Description Compensator Operation
© 2010 Moog GmbH User Manual RKP-II (CA53461-001; Version 2, January 2010) 21
3.5.6 Mechanical Stroke Adjustment, B1
Mechanical Stroke
Adjustment, B1
Fig. 10: Mechanical stroke adjustment, B1
Pos. Description
1 Adjustment screw
2 Seal nut
