14
0688-SOM-00001, Rev: 02 © Tritech International Ltd.
4.3 SeaNet Pro Tools
Bathy Application Menu
The Bathy application menu can be accessed either by clicking the
menu icon in the top left of the top toolbar or by right clicking the
mouse in the Bathy application window.
Here you can access all settings and information screens for the bathy.
Setup
Set Auto or Manual values for Local VOS, Density, and
Barometric. If Auto, the application calculates the correct
based on Bathymetric data available. Otherwise manually
entered values must be applied in the environmental settings.
Display Box Select - Toggles the display between Salinity or
Conductivity in the top right of the main Bathy Screen.
Alternative Depth Formula - Uses the UNESCO standard
depth calculation described in Appendix B .
Depth Alarm - Set the depth range for alert. When activated,
the Bathymetric Display will flash.
Units - Selects units of measurement Meters, Feet, Fathom
or Yards.
Coecients / View DQ Coecients
Opens a pop-up window displaying all coefficient data relating to the
Digiquarts. These values are calculated during the calibration process
of the Bathy.
This data is for information only and cannot be modified. If Coefficient
values need to be updated please refer to the Coeffs Tab in the Device
Configuration window as outlined in section 3.6
Coecients / View CT Coecients
This is a legacy option from the V3 Bathy and is not relevant to V7 systems.
Only the CT probe serial number is available to view.
