380D Digital-to-Analog Converter
Remote Control Operation
Figure 3: Remote Operation with 12V Trigger
In figure 3 we have a Nēo 380D, equipped with both the “MiND” and variable output options, connected to a 330A Amplifier
via their respective 12V triggers (using a 1/8” mini-jack cable); The 12V trigger output on the 380D is connected to the 12V
trigger input on the 330A. When you launch the “MiND” on your smart device (iPad, iPhone, Android Device) and select this
system’s ZONE, the 330A will automatically turn on. To shut down the system, press “Off” for this ZONE in the “MiND” app.
Figure 4: Remote Operation with SimLink™
In figure 4 we have a 180 “MiND” Music Streamer connected to a Nēo 380D DAC via their respective SimLink™ ports (using a
1/8” mini-jack cable), and the 380D connected to a 340i Integrated Amplifier also via their respective SimLink™ ports. When
you launch the MiND App on your smart device (iPad, iPhone, Android Device) and select this system’s ZONE, the 180 “MiND”,
380D and 340i will alll turn on. As well, the 380D will automatically switch to the MiND input. To shut down the system,
press “Off” for this ZONE in the “MiND” app.
Figure 5: Remote Operation with SimLink™ and 12V Trigger
In figure 5 we have a Nēo 380D DAC connected to a 350P Preamplifier via their respective SimLink™ ports (using a 1/8”
mini-jack cable), and the 350P is connected to a 330A Amplifier via their respective 12V triggers (also using a 1/8” mini-jack
cable). When you turn on the 380D via remote control (or its Standby button), both the 350P and 330A will turn on
automatically. The same rule applies when you put the 380D into Standby mode.
____________________________________________________________________________________
10
