MOON Orion DVD Transport / Player
Audio Connections
You can use either the analog audio outputs (if equipped), the digital audio outputs, or both depending
on your system requirements. If you are using a digital surround processor, such as the Moon
Attraction or the Moon Stargate, it is recommended that you to use a digital audio connection. If
you want to use your Moon Orion-A or Orion-AF DVD Transport / Player with an analog stereo
preamplifier or integrated amplifier, you must use an analog audio output connection. If you are not
sure, ask your dealer for recommendations about your specific setup. Whatever the type of
connection(s) you choose, don’t hesitate to use high quality cables. Poor quality cables can degrade
the overall sonic performance of your system.
F) Digital Audio Output (Electrical)
This output is on RCA type connector. You should use a 75Ω digital audio cable. This is the best of the
two available digital audio connection with the MOON Orion.
G) Digital Audio Output (Optical)
This output is on a Toslink (EIAJ Standard) type connector, requiring a Toslink fiber optic digital audio
cable. Use this type of connection if the component you’re attempting to connect to the MOON Orion
doesn’t support the ‘Electrical Digital Audio Output’ previously described.
H) Analog Audio Output (Orion-A & AF)
This output is on RCA connectors, so you must have a pair of audio cables with RCA terminations.
I) SCART Audio/Video Connection (or Peritel Connection)
This output on a 21-pin SCART connector provides for both RGB and composite video connections, as
well as an analog 2-channel (stereo) audio connection (Orion-A & AF) in a single SCART cable.
____________________________________________________________________________________
Audio Connections 10
