4. Pull RED lever back and upward (engaging manu-
al extension system).
5. Pull “T” handle UP and return to original position;
continue until GREEN, gear- down indicator light on
G1000 annunciation is illuminated and/or lines on visu-
al gear position indicator, on floor, aft of console are
aligned when viewed from directly above indicator (this
will normally take 12 to 20 pulls).
-CAUTION-
DO NOT operate landing gear electrically with
manual extension system engaged. Landing
gear actuator C/B will pop out.
-CAUTION-
DO NOT continue to pull T- Handle after
GEAR DOWN light is ON. Actuator may bind
on Down Stops.
32-30-08 - FINAL CHECKS
1. Raise and lower landing gear through five com-
plete cycles, pausing after each cycle to check required
tolerances and dimensions, and G1000 annunciation
light indications. Make certain no bungee springs are
compressed to solid height and nose gear tire clears
top of wheel well a minimum of .25 in. when landing
gear is retracted. Make adjustments per above proce-
dures, as required, to correct any deficiencies.
2. Retorque all jam nuts.
3. Re- attach main and nose landing gear door links.
Check to see that main and nose landing gear doors
are still rigged per paragraph 32-10-03 and 32-20-03.
32-30-08
