G1000 - Servicing Information
On Condition Servicing
“On Condition” replacement and/or servicing should
occur when an item exhibits conditions, symptoms,
and/or abnormalities defined by the troubleshooting
section of the Garmin G1000 System Maintenance
Manuals
(#190- 00907- 00 Rev A or later FAA ap-
proved revision)
and Garmin G1000/GFC700 System
Maintenance Manual
(#190- 00638- 01 Rev A or later
FAA approved revision)
. Replacement and/or servic-
ing should be made only after the technician trouble-
shoots the system to the extent determined necessary
by using the guidance in this manual along with com-
mon avionics maintenance practices.
G1000 Equipment (Chapters 39 & 77)
ITEM Description/Procedure Interval
G1000 System Complete Visual Inspection - Refer to the
Garmin G1000 System Maintenance Manual
(#190- 00907- 00 Rev A or later FAA approved
revision).
Aircraft Annual
GDU 1040 PFD Remove & Replace On Condition
GDU 1042 MFD Remove & Replace On Condition
GMA 1347 Remove & Replace On Condition
GIA 63 IAU (Qty. 2) Remove & Replace On Condition
GEA 71 EAU Remove & Replace On Condition
GTX 33 Mode S Transpon-
der
Remove & Replace On Condition
GTX 33 Mode S Transpon-
der
Test according to Title 14 CFR ww 91.411 and
91.413 as well as Part 43 Appendix F.
24 Months
GDC 74A Remove & Replace On Condition
GDC 74A Altimeter (system) test according to Title 14 CFR
ww 91.411 and Part 43 Appendix E.
24 Months
GDC 74A Airspeed Function Test. 2000 Hours or 48 Months
GDC 74A Vertical Speed Function Test. 2000 Hours or 48 Months
GRS 77 AHRS Remove & Replace On Condition
GRS 77 AHRS Magnetic variation database update. On Condition
GMU 44 Magnetometer Remove & Replace (with a new serial number
unit)
On Condition
GDL 69/69A (Optional) Remove & Replace On Condition
G1000 Accessories
Configuration Module Re-
placement (Qty. 4)
Remove & Replace On Condition
GEA 71 Backshell Thermo-
couple
Remove & Replace On Condition
OAT Probe Remove & Replace On Condition
Mid- Continent Standby At-
titude Ind.
Remove & Replace On Condition
PFD, MFD, & GIA Cooling
Fans (Qty. 3)
Remove & Replace On Condition
5-20-01
