MOONEY INTERNATIONAL CORPORATION
M20V SERVICE AND MAINTENANCE MANUAL
Date
MAR 2017
Rev Date
Page
9
52- 30- 00 - BAGGAGE COMPARTMENT DOOR -
MAINTENANCE PRACTICES
1. Removal.
The baggage compartment door may be removed to
replace or repair door or to replace a damaged hinge.
A. Remove coat hanger and headliner panel lo-
cated inside and directly under baggage door hinge
area.
B. Pull insulation back to clear rivet shanks.
C. Center punch rivet heads holding hinge half to
fuselage.
D. Carefully drill rivet heads and punch rivets from
holes.
E. Work putty knife or thin piece of aluminum be-
tween outer skin and hinge and inner skin frame and
hinge to break sealant bond.
F. Remove hinge and baggage door assembly
carefully.
G. Clean hinge and hinge mounting area thorough-
ly of all sealant or foreign material.
2. Repair.
The baggage door may be repaired per standard repair
procedures in accordance with AC 43.13- 1B CHG 1.
Repairs may be made to baggage door on airplane if
feasible.
-NOTE-
If repairs are to be made, interior trim panel may
require removal.
3. Installation.
OLD HINGE
A. Place repaired baggage door with old hinge into
position and cleco securely to assure fit of door; check
latching operations.
B. Remove door - assure attachment area is clean
of old sealant.
C. Apply sealant, PR1321- B2 or equivalent, to
hinge attachment area between outer skin and inner
frame.
D. Reinstall door assembly with old hinge and cle-
co hinge for proper placement.
E. Install rivets (AD4 standard, AD5 oversize) in all
holes.
NEW HINGE
A. Place old door assembly with new hinge or new
door assembly and new hinge into position and latch
door in place.
-NOTE-
Hinge mounting area should be clean of old
sealant and debris.
B. Push in on door assembly at top, while door is in
latched position to properly locate door and seal in door
frame.
C. While door is held in place mark holes in new
hinge using holes in outer skin as locators.
-NOTE-
Verify correct position of door p rior to drilling
holes in hinge.
D. Center punch all holes and carefully drill two end
holes. Fasten clecoes in these and recheck door as-
sembly fit, if satisfactory continue drilling all holes.
E. Remove door assembly. Deburr and clean area
completely prior to reinstallation of door assembly.
F. Apply sealant (PR1321- B2 or equivalent) to
hinge mounting flange and between outer skin and
door frame.
G. Reinstall door assembly and cleco securely in
place.
H. Install rivets, (AD4 standard, AD5 oversize) in
all holes. Remove clecoes as rivets are being installed
to keep door aligned.
52- 31- 00 - BAGGAGE COMPARTMENT DOOR -
LATCHING MECHANISM
The baggage compartment door has a direct, non- ad-
justable latching linkage that inserts two pins into hard
points in door frame. This latching mechanism can only
be locked from outside aircraft. An auxiliary exit mecha-
nism is incorporated into this latching mechanism
which allows door to be opened, in an emergency, from
inside, even if outside handle is locked.
-NOTE-
There is no way to shut and latch baggage
compartment door from inside.
Outside handle has to be unlatched and fully opened to
correctly re- engage latching mechanism after use of
inside, auxiliary, exit handle (Figure 52- 5).
There is a spring attached to clevis pin of latch linkage.
This ensures positive re- engagement of clevis pin into
cam slot of outside handle for proper actuation of out-
side latching mechanism.
-NOTE-
Follow procedures in Pilots Operating Handbook/
Airplane Flight Manual (POH/AFM, SECTION III)
for re-engagement of mechanism for proper out-
side handle operation.
52-30-00
