Morgana AutoCreaser Pro 50 - Section 9: PRO Control System

SYSTEM
Page 19
AutoCreaser Pro 50
SECTION 9
The Morgana PRO control system is essentially a computer system just like the PC you
use at home. Unlike your Microsoft Windows PC, the PRO system uses a LINUX operating
system and runs only one program, which is the machine control program for the particular
machine that it is installed on.
ELECTRICS: The PRO Control System.
Block Diagram of the PRO Control System
ITX
Motherboard
Controller
PCB
ATX PSU
E-Stop
240V AC
5V DC / 12V DC / 0V
RED/ YELLOW / BLACK
<- Comms ->
GUI
USB Stick / Flash
Drive
(Hard Drive)
Touch Panel
VGA
Digital<>Analogue
Interface PCB
Machine Control
Processor PCB
Touchscreen
Display
115V AC
Transformer
Assembly
