Morgana Documaster MK3 - Recommended Spares

RECOMMENDED SPARES
PART NUMBER DESCRIPTION
93-021 FEED BELT
93-022 DRIVE BELT - Vacuum Roller
609-011 ‘O’ RING Ø20
609-014 ‘O’ RING Ø15
94-028 LOCK PIN ASSEMBLY - Side Lay
75-365
75-366 HOSE - Vacuum Blow
75-367 HOSE - Separation Air
HOSE - Vacuum
613-137 PLUNGER AND SPRING
613-255 SOLENOID COIL
609-013 ‘O’ RING Ø25
613-365 EMERGENCY STOP SWITCH
652-011 SYSTEM SWITCH
75-378-01 DOCUMASTER CONTROL PCB ASSY + CHIP
125-21-02 DUAL STEPPER DRIVE PCB ASSEMBLY
655-011 PSU UNIT 5V/24V
655-015 PSU UNIT - SWITCH MODE - 24V
76-230-03 PAPER GUIDE ASSEMBLY - Bottom Sensor
76-242 PAPER JAM SENSOR ASSEMBLY
76-154 UPPER SENSOR ASSEMBLY
98-013
ANTI-STATIC BRUSH
609-022
‘O’ RING Ø32
606-035 KNOB - Roller Tilt
76-109
POWER LINK BEARING
76-213-01 BLADE SET - Standard
76-042 DRIVE BELT - FEED BED
607-042 TIMING BELT 160XL
607-048 TIMING BELT TWIN GRIP - 200 DXL 050
608-019 SHOULDER BOLT
75-352 POT & LEAD ASSEMBLY
652-009
75-210-05 LCD DISPLAY UNIT-4LINE
144-04-02 JOYSTICK AND LEAD ASSEMBLY
652-010
COMPRESSOR SWITCH (UK)
COMPRESSOR SWITCH (USA)
655-016 PSU UNIT - SWITCH MODE - 48V
76-156 BLADE POSITION SENSOR
