Page31SYSTEM
FIGURE33
FIGURE34
SupportStrut
PushthetwounitstogethersothatthehooksontheTMP
dockingplatesalignwiththeholesintheBMPsideplates
(seeFigure33).
LifttheBMPlidslightly,pushthesupportstrut(seeFigure
34)andclosethelid.Turnthehandletotherighttolock
theTMPinplace.
HooktheOutfeedConveyorontothesupportpostson
theTMPandconnecttheinterfacecable.
DocuMasterPro
