CREASING/BOOKLETMAKING
FIGURE35
FoldPositionFineTuning
FIGURE36
FineAdjustmentScrew
TurnAnticlockwiseto
RaisetheStaples
TurnClockwiseto
LowertheStaples
LockingScrew
LockingScrew
STAPLEPOSITIONADJUSTMENT
ToolsrequiredIfbothstaplesareconsistentlyoffthespineofthebook
FlatBladeScrewdriverfirstensurethattheBMPisadjustedcorrectlyandthat
deliveryintotheunitisgood.Iftheproblempersists,fine
tuningofthestaplepositionmaybenecessary.Adjust-
mentisviathecentralscrewonthefoldplatemechanism,
locatedbehindtheperspexcover(seeFigure35).
Ifnecessary,adjustthefoldpositionuntilthescrewsalign
withtheholesintheperspexcover.Usingaflatblade
crewdriver,loosenthetwolockingscrews(seeFigure
36).
Turnthefineadjustmentscrew(seeFigure36)clockwise
tolowerthepositionofthestaples(asviewedwhenthe
bookexitstheunit)andanticlockwisetoraisethestaples.
Onequarterturnofthescrewequatestoapproximately
2mmoftravel.
Tightenthelockingscrewsandproduceatestbooklet.
Repeattheprocedureifnecessary.
