Morgana Documaster Pro - Conveyor Clamp Adjustment

Page40
CREASING/BOOKLETMAKING
CONVEYORCLAMPADJUSTMENT
TheTMPconveyorclampsaresettoadefaultpositionat
thefactory,whichgivesagoodtrimoverawidevariety
ofbookletthicknesses.
However,whentrimmingunusuallythickorthinbooklets,
theconveyorclampsmayneedtobeadjusted.
Iftheconveyorclampsaresettooloose,thebookletmay
notbedeliveredcorrectlytothetrimstop,oritmay
bounce
againstthetrimstop.Thiswillresultinthefollowing
problems:
bookletsaretrimmedoutofsquare(thismayalso
indicatethattheleftandrightconveyorclampsareset
unevenly).
Bookletsaretrimmedtooshort.
Iftheconveyorclampsaresettootight,thefollowing
problemmayoccur:
Thecoverofthebookletsarepulled,resultingindam-
agearoundthestaples.
!
!
!
ToolsrequiredProcedure
4mmallenkeyOntheBMPcontrolpanel,setthepapersizeto
2off150mm/6"rule(regardlessofthebookletsize).OncetheBMPbeepsto
confirmitisready,disconnectitfromthemains.
A4>A5
