Morgana Documaster Pro - Page 43

Page41SYSTEM
FIGURE43
Conveyorcover
Adjustment
screw
FIGURE44
Adjustment
screw
ClampRoller
Shaft
ClampRoller
Shaft
OpentheTMPconveyorcover,byliftingtheorange
handscrew(seeFigure43).
Therearetwoclamprollershafts,whichareadjusted
usinga4mmallenkey(seeFigure44).
AdjustingtheConveyorClamps
Toadjusttheconveyorclamp:
Turntheadjustmentscrewsclockwisetoincreasethe
gap(reducingclamppressure)
Turntheadjustmentscrewsant-clockwisetoreduce
thegap(increasingclamppressure)
!
!
DocuMasterPro
