MotorisedInfeedSocket
FIGURE9
FIGURE10
Length
Adjustment
HandScrew
RearHandScrew
ConnecttheMotorisedInfeedinterfacecabletothe
socketonthetopoftheBMP(seeFigure9).
PositiontheMotorisedInfeedontheBMP,sothatthe
fixingclips(seeFigure8)locateinsidetheBMPinfeed.
Fittherearhandscrew(seeFigure10)andthentighten
thetwosidehandscrews.
Fitthepapertray(seeFigure7)ifrequired.
