REGULAR INSPECTION B-17
(1) When replacing the machining chamber observation window, contact Mori Seiki
Service Department and use a window of the specified type. Mori Seiki does not
accept responsibility for problems arising from the use of a non-specified window
type.
(2) The machining chamber observation window is a consumable part and is not covered
by the warranty.
(3) Check the mounting direction of the window with the sticker affixed to the window that
indicates the outer side of the window pane.
<Procedure>
1) To secure the space where you can work safely, remove tools from the spindle and
workpieces and fixtures from the table.
2) Turn OFF the main power.
3) Step inside the machining chamber and remove bolts from the rear plate securing the window
on the backside of the door.
(1) Take care not to slip and fall in the machining chamber.
(2) Hold the window securely being careful not to drop the window.
4) Remove the old window.
In case the window pane is damaged, take sufficient care not to be injured by touching the
damaged part of the pane.
5) Remove silicon from the window frame of the door.
6) Install a new window according to the following procedure:
a) Check the mounting direction (inner or outer side) of the window with the sticker affixed to
the window. Apply silicon around the window frame on the outer side.
b) Install the window.
c) Fix the window by tightening bolts on the rear plate.
7) Set the replacement date on the periodical inspection 1 screen.
This screen may not displayed depending on the machine model.
Operation Manual (FUNCTION SELECTION KEYS AND DISPLAYS SCREENS:
Regular Interval Maintenance Screen)
This completes the machining chamber observation window replacement procedure.
NOTE
NOTE
NOTE
NOTE
