REGULAR INSPECTION B-23
(1) The type of the battery used in the NC depends on the machine model.
(2) [ ]: Part number of the NC unit manufacturer
(3)
*1
Type and number of batteries may vary depending on machines models. See
the actual machine for details.
*2
The number of batteries to be used varies depending on the machine model.
Check the number by looking at the number of battery cases.
Type 2
MSC-803
*1
• Electrical cabinet side
Battery unit × 1 set
E30027
[ER6 BKO-NC2157H01]
• Operation panel side
Battery unit × 1 set
E03031 [ER3V]
Battery unit × 1 set
E30028 [ER6-B4D-01]
MSG-803
Battery unit × 1 set
E30027
[ER6 BKO-NC2157H01]
MSX-803
MSX-803III
Type 3
MSC-803
*1
Regular lithium photo battery
× 2 pcs.
*2
2CR5 (6 V 1300 mAh)
Regular lithium photo battery
× 2 pcs.
*2
2CR5 (6 V 1300 mAh)
MSG-805
*1
MSX-805
*1
MSX-805III
*1
Type 4
MSC-700
MSC-701
Lithium battery
E30001 [A02B-0200-K102]
Lithium battery
E30234 [A06B-6114-K504]
Type NC Unit Memory Back-up Battery
Absolute Position Sensing
Battery
NOTE
