Morphy Richards SPEED STEAMPRO - Steam Generator Overview

4
(1) Filling aperture
(2) Dirty water chamber
(3) Dirty water emptying hole
(4) Temperature indicator light
(5) Temperature dial
(6) Soleplate
(7) Steam trigger
(8) Iron handle
(9) Iron-to-base lock
(10) Cable support
(11) Water tank handle
(12) Detachable water tank
(13) Iron locking hook
(14) Iron rest plate
(15) Rear docking slot
(16) Control panel
(17) Base unit
(18) Cord storage groove
(19) Cord storage
Steam generator overview
4
5
6
18
19
7
8
11
16
17
9
10
12
13 1514
1 3
2 3
1
2
18
