10
Reversing the door
Remove the door shelf
Door stopper-left
press in
wa
rdly
if some parts
are not shown in the picture below, please
ignore the relevant description.
2.
Remove part①, then take down
part② from the top right side of
refrigerator. Unscrew screws③ by a
8mm socket driver or a spanner, and
remove hinge④. Please hold upper
door by hand when installing. Use a
putty knife or thin-blade screwdriver
to prize part⑤ which is at the top left
corner of the refrigerator.
③
①
②
④
⑤
①Self-tapping screw
②Upper hinge cover
③Special flange screw
④Upper hinge
⑤Screw hole cover
3. Remove the upper door from the
middle hinge by carefully lifting the
door straight up.
,
4. Place the upper door on a smooth
surface with its upper cover upwards.
To Next Page
