Morris T72307HM - Reversing the Door: Component Transfer; Steps 5-10: Reassembling Components

( provided in the plastic bag) to
11
6. Unscrew the two special flange self-
tapping screws which are used for
fixing the middle hinge part, then
remove the middle hinge part that hold
the lower door in place.
NOTE: When removing the door, watch
for washer(s) between the center hinge
and the upper of the lower door that
may stick to the door. Don't lose it.
5.
Loose screw ③ and take down
part ② and part ①, Install
replacement door stopper-left ④
(provided in the plastic bag) and
part ②(stop block) to the left side
with screw③. Keep part ① with the
appliance for future reference.
①
②
③
①Door stopper
②Stop block
③Self-tapping screw
④
④Door stopper-left
8. Change screw hole covers on middle
cover plate from left to right (as shown
in figure below).
screw hole covers
screw hole covers
②
③
①
②
Door stopper
③
Stop block
④
Self-tapping screw
9. Lay the refrigerator on soft foam
packaging or similar material. Remove
both adjustable bottom feet parts①,
then remove the lower hinge part ②by
unscrewing the special flange self-
tapping screws③.
①
②
③
①Adjustable bottom feet part
②Lower hinge part(right)
③Self-tapping screw
10.
Remove part ① from the lower
hinge part (right), loose out the
lower hinge pin, change it to the
reverse hole site, and then tighten
into position, then install part ① on
the lower hinge pin.
①
7. Place the lower door on a smooth
surface with its panel upwards.
Loose screw
④
and take down part
②
and part , then Install door stopper-
left
the left side and tighten them
securely.
Door stopper-left
①
③
①
④
